EX-6124

1. Description

The EX-6124 is a multi-protocol RS-232/422/485 serial device server. Which is designed to con-
nect four RS-232/422/485 serial devices, including POS, barcode readers, sensors, meters, CNC
controllers and PLCs to an IP-based Ethernet network. The serial devices are thus connected to
the network and are thus available for sharing on the Internet, with remote configuration using the
extensive network protocols such as TCP server, TCP client, UDP, VCOM, serial Telnet,
RFC2217, remote pair master slave, Modbus RTU. To be backward compatible with the legacy
serial device running the existing COM port application software, EX-6124 provides a virtual COM
port redirection driver (VCOM) that perfectly migrates your serial application without modifying the
software. In addition, serial devices with remote pair master-slave mode can communicate with
each other via peer-to-peer mode without the need for an intermediate PC or conversion software.
Features:
•
4x RS-232/422/485 Port via RJ45 Ethernet 10/100Mbps
•
Up to 921.6 Kbps Baud Rate
•
Serial Mode: RS-232, RS-422, RS-485 2-wire & 4-wire
•
Network Protocols: TCP Server, TCP Client, UDP, VCOM, Serial Telnet, RFC2217, Remote-
Pair-Master-Slave, Modbus Server, Modbus Client and SNMP
•
Configuration: Windows-based VCOM-Administrator-Utility and Web-Browser
•
Support 15KV ESD-Protection for all serial Signals
•
Support 5V over serial Connector
•
Certificate for

2. Extent of Delivery

Before you integrate the EX-6124 into your network, you should first check the contents of the
delivery:
•
EX-6124
•
Power Supply (12V/3A)
•
Manual
•
Driver CD
