3. Layout, Connections & LED's
3.2 Connections & LED's
DB 9M (RS-485 2-wire):
RJ45 Port:
LED's:
LED Name
Power/Act LED
(RJ45)
PoE LED
Orange
(RJ45)
Status LED
TXD LED
(right)
RXD LED
(left)
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
Serial 9 Pin D-SUB Connector (RS-485 2-wire)
Pin
1
2
3 DATA+(B)
RJ45 Port
Pin Signal
1 BI_DA+
2 BI_DA-
3 BI_DB+
Color
Steady on: Power is On
Green Blinking: Transferring data on the Network
Off: Power is Off
Steady on: Extracting the power from LAN cable (PoE model only)
Off: LAN cable PoE Power is not extracted
Blinking: The unit has booted
Green (25 ~ 30 seconds required from power up)
Off: The unit is not booted yet
Blinking: The Serial Port is sending out data
Green
Off: The Serial Port is not sending out any data
Blinking: The Serial Port is receiving data
Green
Off: The Serial Port is not receiving any data
Signal Pin
NC 4
NC 5
6
Pin Signal
4 BI_DC+
5 BI_DC-
6 BI_DB-
LED Function
17
Signal Pin
DATA-(A) 7
GROUND 8
NC 9
Pin Signal
7 BI_DD+
8 BI_DD-
