1. Description

The EX-6100 is a metal Gigabit Ethernet switch for 4 devices. The switch enables you
to deliver power and data to your Ethernet devices on the network via a single Ethernet
cable. It supports the 10/100/1000 Base-T Ethernet standards. Fully IEEE 802.3at com-
pliant PoE (PSE=Power Source Equipment) Type 1 and 2 operation supported. The
maximum power at the PoE ports are for Type 1 13W and for Type 2 25,5W. The exter-
nal power supply via the +48-57V terminal block makes it easy to provide the required
power. It uses data transfer rates up to 1000Mbit/s. It provides a secure and very high
data transfer on each single port. In addition, the EX-6100PoE can also be used in the
extended temperature range from -40C° to +85C°. The EX-6100PoE can easily be
mounted on a carrier rail in a server rack by using the supplied DIN-Rail kit.
Features:
•
Compatible for 10/100/1000Mbit/s Ethernet
•
Maximum Output: Typ 1: 13W / Typ 2: 25,5W
•
All Operating Systems are supported
•
Extended Temperture Range from -40C° bis +85C°
•
Certificate for

2. Extent of Delivery

Before you integrate the EX-6100PoE into your network, you should first check the con-
tents of the delivery:
•
EX-6100PoE
•
DIN-Rail Kit (EX-6096)
•
Manual
