EX-6114

1. Description

The EX-6114 is a multi-protocol RS-232 serial device server. Which is designed to connect four
RS-232 serial devices, including POS, barcode readers, sensors, meters, CNC controllers and
PLCs to an IP-based Ethernet network. The serial devices are thus connected to the network and
are thus available for sharing on the Internet, with remote configuration using the extensive net-
work protocols such as TCP server, TCP client, UDP, VCOM, serial Telnet, RFC2217, remote pair
master slave, Modbus RTU. To be backward compatible with the legacy serial device running the
existing COM port application software, EX-6114 provides a virtual COM port redirection driver
(VCOM) that perfectly migrates your serial application without modifying the software. In addition,
serial devices with remote pair master-slave mode can communicate with each other via peer-to-
peer mode without the need for an intermediate PC or conversion software.
Features:
•
4x RS-232 Port via RJ45 Ethernet 10/100Mbps
•
Up to 921.6 Kbps Baud Rate
•
Network Protocols: TCP Server, TCP Client, UDP, VCOM, Serial Telnet, RFC2217, Remote-
Pair-Master-Slave, Modbus Server, Modbus Client and SNMP
•
Configuration: Windows-based VCOM-Administrator-Utility and Web-Browser
•
Support 15KV ESD-Protection for all serial Signals
•
Support 5V over serial Connector
•
Certificate for

2. Extent of Delivery

Before you integrate the EX-6114 into your network, you should first check the contents of the
delivery:
•
EX-6114
•
Power Supply (12V/3A)
•
Manual
•
Driver CD
