- Car stereo with an ISO connector
- Autoradio avec connecteur ISO
- Autorradio con conector ISO
- Autoradio mit ISO-Anschluss
6
Not used
www.parrot.com
• 1: 12V ignition (orange)
• 2: 12V battery supply (red)
• 3: Ground
• 4: Connection to the vehicle's power supply
3
4
2
1
5
6
• 5 : Connection to the vehicle's speakers
• Rear right speaker (purple / purple-black)
• Front right speaker (grey / grey-black)
• Front left speaker (white / white-black)
• Rear left speaker (green / green-black)
• 6 : This wiring is not used.
- Autoradio con connettore ISO
- Autoradio met ISO-connector
- Auto-rádio com conector ISO
