Sharp UA-KIL80E Bedienungsanleitung Seite 9

1 Power ON/OFF Button
2 Light Sensor
3 Auto Mode Button, Lamp
4 Plasmacluster Ion Spot Button, Lamp
5 Mode Button, Lamps
Humidify ON/OFF Button, Lamp
6
Filter Reset Button
(Touch 3 sec.)
7 Filter Maintenance Lamp
Clean Ion Shower Button, Lamp
8
Dust Box Reset Button
(Touch 3 sec.)
(Only UA-KIL80E)
Dust Box Reset Lamp
9
(Only UA-KIL80E)
Switching Display Button
10
Child-Lock Button
(Touch 3 sec.)
11 Child-Lock Lamp
(White)
12 ON/OFF Timer Button, Lamp
13 Unit Replacement Lamp
14 Plasmacluster Ion Indicator
Cleanliness Indicator
• Indicates the air purity of the room with colour changes
and flashing speeds.
Cleanliness Indicator turns off when the air is clean.
When the air changes from dirty to clean, it flashes blue
for a while and then turns off.
15
Clean
Turn off or Blue (Flashing)
Yellow (Flashing)
Impure
Red (Flashing fast)
(White)
(White)
(White)
(White)
(Orange)
(White)
(Orange)
(White)
(Red)
(Blue)
EN-7
Display
• Timer
Indicates setting time or remaining time of
ON/OFF timer.
• PM2.5 Concentration*
PM2.5 10 μg/m 3 to 499 μg/m
3
9 μg/m
or less
• Temperature*
Temperature 0 C to 50
16 o
-1 o C
or less
• Humidity*
Humidity 25 % to 75 % is displayed.
24 %
or less
• Wattage*
Indicates wattage by current operation.
* The displayed numbers are approximate.
Pre-Filter Auto Cleaning Indicator
17
(Only UA-KIL80E)
Humidifying Indicator
White Humidify ON
18
Off Humidify OFF
Red (Flashing) the product needs water
PM2.5 Indicator
(White)
19 Indicates the Sensitive Dust Sensor detects microscopic
dust.
Dust Indicator
(White)
20
Indicates the Sensitive Dust Sensor detects usual dust.
Odour Indicator
(White)
21
Indicates the Odour Sensor detects odours.
3 is displayed.
3
500 μg/m
or more
C is displayed.
o
51 o C
or more
76 %
or more
(White)
