Start-up
The bore holes (J) can be used for installation
with a flush-mounting box.
• Now drill the bore holes.
If you are working with a stone wall, drill the
marked 5 mm holes and insert the plugs supplied.
If you are working with a wooden wall, you can
pre-drill 1.5 mm holes to make screws easier to
insert.
• Use the supplied screws and plugs (K) to fasten
the mounting plate to the wall (see figure 4).
Attach the clip-on frame (A) to the mounting
•
plate.
Place the remote control (B) back into the frame
•
(see figure 1). Make sure that "TOP" and the ar-
rows on the back side point upwards and that the
clips on the mounting plate latch into the open-
ings on the remote control.
5.2.3

Installation in multiple combinations

You can mount the wall-mount remote control with the
attachment frame (A) provided or use it with frames of
other manufacturers as well as integrate the remote con-
trol (B) into a multi-gang frame. You can flexibly fix the
mounting plate (F) to the wall using adhesive strips or
screws. For mounting with multiple combinations, make
36
