UK
access the pool. Do not immerse the filter system, power cable or plug in water or in any
other liquids. The filter system's pump is designed to ensure good protection against wa-
ter spray. However, it should still be installed in such a way to ensure adequate protection
from the weather.
Check scoop of delivery
Note! Risk of damage! The product may be damaged if you open the packaging with a
sharp knife or other sharp objects without due care and attention. Please open the pack-
aging very carefully.
- Remove the product from the packaging
- Check that all the included items have been delivered in full
- Check whether the item, or parts thereof, exhibit damager. If there is damage, do not
use the product. Get in contact with the service address stated at the end of the manual.
Operation
The filter balls in the filter tank ensure that dirt particles and floating debris are effective-
ly filtered over a long period of time. Dirty water is drawn from the pool via the suction
pipe through the filter pump and then fed from above into the filter tank. As the water
flows through the filter balls in the filter tank, dirt particles are deposed in the filter balls
and thus filtered out of the pool water. The purified water then flows through the return
pipe back into the pool.
For the operation of the filter system, you need a skimmer (surface skimmer). Either an
integrated skimmer (built into the pool wall) or a suspended skimmer (attachment to the
pool wall).
Positioning
The installation area you set between the skimmer and the inlet nozzle so, that there
is an adequate safety margin to the pool wall. We recommend putting the filter system
in addiction on base plates (for example: washed concrete slabs etc.). these have to be
installed with the spirit level.
If you have sunk your pool partially or completely, so it makes sense to place the filter
pump in a filter slot, which should connect directly to the pool. Is your filter pump housed
in a filter slot, so it has to be insured, that the filter slot can't be flooded. For this purpose,
you should bring in a roller-burnishing (crushed rock) in the range of the filter slot, so that
the surrounding- and rain water can seep away. It would be ideal if there is a direct con-
nection to the drain in the sump of the filter shaft (or sludge pump, with automatic float-
ing switch). It is important to ensure that the filter slot should never be airtight, because
this may cause damage, due to the condensation water, on the filter pump. The size of
the filter shaft should be selected so that work can be performed on the filter system.
