ENGLISH
When installing, be sure to follow carefully the instructions given in this manual.
The manufacturer declines all responsibilities for damage to equipment or people caused by non-standard system
installations or modifications.
Use the conditioner exclusively for the use envisaged by the manufacturer and make no arbitrary changes or alterations to the
appliance.
Never poke your hands inside the grid of the vents and avoid introducing any object into the system.
BEFORE INSTALLING THE SYSTEM, DISCONNECT ALL CONNECTIONS TO THE VEHICLE BATTERY.
Install the roof unit securely to prevent it tipping or falling.
During the assembly phases and the creation of holes in the vehicle, make sure that you do not damage wirings or piping of
systems already installed.
When working near the heat exchangers of the condenser and the evaporator, be careful not to cut yourself on the sharp edges
of the fins.
If the electrical wires have to pass through walls with sharp edges, use protective pipes or specific channels.
Securely fasten the electrical wires, paying special attention to their route along metal walls that conduct electricity; also avoid
contact with sharp elements.
Before beginning installation and after positioning the unit on the roof, check that the openings for the air inlet and outlets on the
condenser are not blocked or covered.
Check whether, following the assembly of the conditioner, it is necessary to change the registration of the height of the vehicle
indicated in the log (contact the vehicle manufacturer).
Switch off the conditioner before using automatic washing devices to clean the vehicle.
1. Disconnect the battery.
2. Installation operations must be carried out exclusively by a specialised technician who is aware of the dangers connected
with installation and the relative prescriptions.
3. Before positioning the unit on the roof of the vehicle, check that it is possible to access it and that it can support the
weight of the conditioner you intend to install.
4. Remove the white external cover of the group, disconnecting the condenser fan.
5. Rest Sleeping Well Oblò on an adequate surface, making sure that it is stable and that the inner diffuser is not damaged.
6. Remove the hatch from the roof of the vehicle.
7. Don't remove the original gasket. It isn't necessary remove the eventual original fixing brackets of the hatch (see fig.3).
8. Place the group over the hatch, keeping attention to avoid damages to the inferior plastic part. Align the rear profile of the
diffuser to the original gasket of the hatch: the Sleeping Well Oblò will be behind the opening. (see pic.3)
Fix the supplied frame over the air diffuser checking that, after the installation, it will cover the hatch space correctly.
Ensure that the front and side slots on the air diffuser remain free after it has been fastened in place.


GENERAL WARNINGS

MOUNTING STEPS

SLEEPING WELL OBLò
Sleeping Well Oblò_09_01/2009
