Line Tech PE1.4 Serie Montage- Und Wartungsanleitung Seite 23

LINE TECH – POSITIONIEREINHEIT MIT KGT
Nenngrösse
Hub
Bezeichnung
[mm]
PE2.4...NR... 50
115
175
240
305
370
435
500
565
630
695
760
825
890
955
1020
1100
1145
1220
1275
1535
1795
2050
2310
2570
www.linetech.ch
Abmessungen
L L L
3 4
[mm] [mm] [mm]
330 62.5 62.5
395 62.5 62.5
455 62.5 62.5
520 62.5 62.5
585 62.5 62.5
650 62.5 62.5
715 62.5 62.5
780 62.5 62.5
845 62.5 62.5
910 62.5 62.5
975 62.5 62.5
1040 62.5 62.5
1105 62.5 62.5
1170 62.5 62.5
1235 62.5 62.5
1300 62.5 62.5
1380 62.5 62.5
1425 62.5 62.5
1500 62.5 62.5
1555 62.5 62.5
1815 62.5 62.5
2075 62.5 62.5
2330 62.5 62.5
2590 62.5 62.5
2850 62.5 62.5
A
1
n A
2
1 100 100
2 67.5 67.5
2 97.5 97.5
3 65 65
3 97.5 97.5
4 65 65
4 97.5 97.5
5 65 65
5 97.5 97.5
6 65 65
6 97.5 97.5
7 65 65
7 97.5 97.5
8 65 65
8 97.5 97.5
9 65 65
9 105 105
10 62.5 62.5
10 100 100
11 62.5 62.5
13 62.5 62.5
15 62.5 62.5
17 60 60
19 60 60
21 60 60
Spindellänge Gewicht
[mm] [kg]
343 9.8
408 10.3
468 10.8
533 11.3
598 11.8
663 12.3
728 12.8
793 13.3
858 14.0
923 14.5
988 15.0
1053 15.5
1118 16.0
1183 16.5
1248 17.0
1313 17.5
1393 18.0
1438 18.5
1513 19.0
1568 19.5
1828 21.5
2088 23.5
2343 25.5
2603 28.0
2863 30.0
