NEC MultiSync FP Serie Handbuch Seite 26

If your computer is equipped with USB and uses the Windows
operating system and you want to operate the monitor's user controls
using your system, you can install USB support by using the following
procedure. To attach the USB port on your MultiSync FP Series monitor to
a USB port on your system:
1. Using the supplied USB cable, connect the USB Series B connector end
to the USB upstream port on the monitor (Figure 1).
2. Connect the other end of the supplied cable to the USB downstream
port on the computer (or to a USB Hub attached to the computer)
(Figure 1).
3. Install the supplied Monitor Control Software.
100
95
75
25
5
0
Downloaded from www.Manualslib.com
USB downstream port
manuals search engine
Figure 1
E - 5
®
98
USB upstream port
USB series B
connector end
