4. Connect one end of the power cord to the MultiSync FP Series monitor
and the other end to the power outlet (Figure D.1).
5. Turn on the monitor (Figure E.1) and the computer.
6. The Factory Setting for your monitor is set for D-SUB installation. If you
are using a BNC cable connection, push the BNC/D-SUB button on the
front of the monitor (Figure E.1) to switch settings.
NOTE:
100
95
75
25
5
0
Downloaded from www.Manualslib.com
Computer
15-pin mini
D-SUB
Signal Cable
Figure A.1
If you have any problems, please refer to the Troubleshooting
section of this User's Manual.
Signal Cable
Figure A.2
manuals search engine
Figure B.1
Mac Adapter
(not included)
Figure B.2
E - 3
Computer
Mac Adapter
(not included)
Signal Cable
Signal
Cable
