6 Specifications

Registration numbers
Microphone: . . . . . . . . . ETS G000 258L CEPT-LPD
Receiver: . . . . . . . . . . . . ETS G000 257L CEPT-LPD
Carrier frequency
TXS-400SET: . . . . . . . . 433.05 MHz
TXS-402SET: . . . . . . . . 433.55 MHz
TXS-440SET: . . . . . . . . 433.05 MHz
TXS-442SET: . . . . . . . . 433.55 MHz
Transmission power: . . . . . 15 mW
Frequency stability: . . . . . .±0.005 %/25 °C,
Modulation: . . . . . . . . . . . . FM, ±40 kHz
RF S/N ratio: . . . . . . . . . . . > 80 dB
Audio range: . . . . . . . . . . . 50 – 15 000 Hz, ±3 dB
Dynamic range: . . . . . . . . . 100 dB
THD: . . . . . . . . . . . . . . . . . < 0.8 %
Audio outputs
XLR: . . . . . . . . . . . . . . . 15 mV/600 Ω, bal.
6.3 mm jack: . . . . . . . . . 0 – 70 mV/10 kΩ, unbal.
Operating range: . . . . . . . . approx. 30 m
Ambient temperature: . . . . 0 – 40 °C
Power supply
Microphone: . . . . . . . . . 9 V battery,
Receiver: . . . . . . . . . . . . 12 V /300 mA
Dimensions (W x H x D)
Microphone: . . . . . . . . . Ø 54/36 x 245 mm
Receiver: . . . . . . . . . . . . 220 x 40 x 115 mm
Plug-in power supply: . . 52 x 66.5 x 41 mm
Weight
Microphone
(without battery): . . . . . . 220 g
Receiver: . . . . . . . . . . . . 520 g
Plug-in power supply: . . 250 g
According to the manufacturer.
Subject to change.
Downloaded from www.Manualslib.com
quartz-controlled
lifetime approx. 6 – 8 h
via supplied plug-in
power supply connected
to 230 V~/50 Hz/6 VA
