Cleaning
- Spring assisted mechanism, can be tipped in 4 directions, with locks
- Inner frame with pleated fl ynet + blind (optional fl ynet only)
Aperture:
Corner radius:
Size dome:
Height over roof
Free-air-fl ow:
Outer frame material:
Dome material 4751P/4753P
Other models:

Care Instructions

The roofl ight should only be washed by hand, using a sponge
with plenty of clean water to avoid scratching. Caustic detergents
and solvents may attack the plastic and make it brittle or disinte-
grate.
For easier cleaning of the dome it can be removed from the frame
by releasing the four screws holding the handle arms (models from
May 2010, Torx TK10 screws).
Make sure that only the original screws are used when replacing
the dome and that they enter the thread in the plastic correctly.
Do not over-tighten.
Never remove the screws holding the dome and the handles toge-
ther (see picture 12).
and should only be handled by an approved dealers.
To remove the inner frame for cleaning, with the fl ynet and blind
attached, follow the reverse of the fi tting instructions; removing
covers and screws.

Technical Information

Product description
- Clear or opaque domes with free airfl ow
- concealed fi xing screws
- ECE R43 Whole Vehicle Type Approved
(Please ask for further details.)
Technical Data:
model 44P/ 4400P:
model 46P/ 4600P:
model 4751P/ 4753P:
(See picture 12)
These are secured by a torque screwdriver
400 x 400 mm
560 x 560 mm
Please refer to model options
Polypropylene
PC/ PMMA + SAN
Polypropylene
5
25 mm
117 mm
92 mm
96 mm
