Warning!
Fitting position
Aperture size
Roof thickness
Fitting direction
Fixing screws
- Upper frame
- Inner frame
Sealing
Fitting

Fitting Instructions

Never stand on the dome of the roofl ight!
(See picture 1)
Choose a fi tting position that will not interfere with other roof
mounted components (e.g. roof-racks/antenna's etc.) and avoid
internally installed electrical cables and furniture, which could
impede the correct operation of the roofl ight.
The roofl ight should only be fi tted to a fl at roof surface, both in-
ternally and externally.
400x400 mm (see technical data page 5)
Ensure the correct roofl ight is selected for the roof thickness (for
available size options see technical data page 6).
Roofl ights must only be fi tted with the operating handles facing
the front and rear of the vehicle, not across the vehicle.
Pan 3,5 mm/head according to DIN ISO 7049 (DIN 7981)
Screw size - When fully tightened the screw should enter the outer
frame about 10 mm.
Screw length for fi tting of inner frame 13 mm (or plastic screws for big hole)
Do not use countersunk screws as they will damage the roofl ight
frame (see picture 4).
Use only long term fl exible sealant, suitable for external use, (not
supplied), and also suitable for the material of the upper frame.
Consult your sealant supplier.
Separate the inner and outer frames and fi t the outer frame to
the outside of the roof aperture onto a bed of sealant, with the
operating handles facing front and rear of the vehicle.
Place over the screw holes on the inside of the frame, the 8
fi xing brackets; four in each corner, four in the centre of each
side. Secure with screws
Attention: Do not over-tighten the screws, stop as soon as the
brackets start to distort.
Max. Torque 0.5 Nm
To fi t the inner frame, gently pull out the pointed ends of the cover
profi les to release them and reveal the fi xing points.
There are two fi xing holes in each corner of the frame, for two
fi xing options (See picture 6 -
It is recommended that the in ner frame is fi tted with the blinds to
the side of the vehicle, opposing the operating handles..
3
(see picture 2). Screws not supplied.
(See picture 3).
7).
(See picture 5).
