HAWA Frontslide 140 matic Montageanleitung Seite 8

Hawa Frontslide 60 matic 100 matic 140 matic
1 Table of contents
Contents
2 Product information
3 Safety regulations
4 Abbreviations, symbols
5 Overviews
6 Planning
7 Calculation
8 Pre-assembly
9 Assembly
10 Disassembly
11 Optional
8/44
5.1 Overview: Hawa Frontslide 60 matic, 100 matic and 140 matic
5.2 Overview: position numbers
6.1 Planning: Hawa Frontslide 60 matic
6.2 Planning: Angled profile support for Hawa Frontslide 60 matic
6.3 Planning: Angled profile support with spacer profile for Hawa Frontslide 60 matic
6.4 Planning: Hawa Frontslide 100 matic
6.5 Planning: Hawa Frontslide 140 matic
6.6 Planning: Guide situations
7.1 Calculation: Sliding shutter width, top track and bottom guide channel
7.2 Calculation: Toothed belt length
7.3 Calculation: Suspension points
7.4 Calculation: Drill holes, sliding shutter
7.5 Calculation: Drill holes, bottom sliding shutter guide
8.1 Pre-assembly: Sliding shutter
9.1 Assembly: Top track
9.2 Assembly: Hawa Motronic 60, Hawa Motronic 100 or Hawa Motronic 140
9.3 Assembly: Bottom guide channel
9.4 Assembly: Sliding shutter
9.5 Assembly: End stop
9.6 Assembly: Toothed belt
9.7 Assembly: Tensioning the toothed belt
9.8 Assembly: Commissioning
9.9 Assembly: Cover
10.1 Disassembly: Toothed belt lock
11.1 Optional: Assembly using hammer head bolts type 28/15 provided by the customer
11.2 Optional: Cover cap
11.3 Optional: Connecting pins
Page
9
10
11
12
13
14
16
17
18
19
20
21
21
22
23
24
25
27
28
29
30
32
33
34
37
38
39
40
41
41
