Stand feature (optional, # 90553)


Installation
. Ass'y stand frame () and Ass'y stand base () will be fixed by using 4 screws of BH M4x8 (4) size.
. Ass'y stand (9 + () and LCD monitor will be fixed by using 4 screws of TH 4x8 (3) size.
Tilt adjustment
STAND mounting
Construction
Finish
Dimensions (HxWxD)
Weight
Downloaded from www.Manualslib.com
4
-° ~ 40° (up or down)
four BH M4 x 8L
Plastic and Metal
Painting
305,7 x 99,5 x 00
.0kg
manuals search engine
3
Assembly part's list
No. Q'ty Part name
1
 Ass'y stand frame
2
 Ass'y stand base
3
4 Screw
4 4 Screw
6
Description
TH 4x8 (black) size screw
BH M4x8 (Nikel/white) size
screw
