7. Mounting Options

Wall and ceiling mounting (optional, # 90394)
The bracket is a simple wall and ceiling mount for the LCD monitor.
1
 Tilt angle range
 Swivel range
3 Monitor mounting
Note
Material
Surface finish
Max. load
Dimensions
Weight
Downloaded from www.Manualslib.com
2
bending
-5° to about 5° (up or down)
Unlimited 80°
Four M4x5 screws, supplied.
The screws may not insert deeper than 6 mm inside the case.
Die cast and aluminum (PT /4 threaded pipe)
Light-gray polyester power coating
9.0 kg
Refer to the dimensional drawings
.0 kg
manuals search engine
panning
5
3
