TECHNICAL DATA
Technical characteristics - controller
Dimensions: ............................................................. 113mm x 163mm x 48mm
Controller weight....................................................... 391g
Controller housing .................................................... ASA - thermoplastics
Supply voltage .......................................................... 230 V ~ , 50 Hz
Power consumption .................................................. 5 VA
Cross-sectional area of network conductors............... 0.75 to 1.5mm2
Degree of protection ................................................. IP20 according to EN 60529
Safety class .............................................................. I according to EN 60730-1
Permissible ambient temperature .............................. 5 °C to +40 °C
Permissible relative humidity .................................... max. 85 % rH at 25 °C
Storage temperature ................................................. -20 °C to +65 °C
Relay output
R1 ............................................................................ pot. free, max. 4 (1) A ~, 230 V ~
R4, R5, R6 ............................................................... 4 (1) A ~, 230 V ~
Triac output
R2, R3 ..................................................................... 1 (1) A ~, 230 V~
Program timer Type .................................................. 7-day program timer
Min. interval .............................................................. 15 min
Accuracy of the installed program timer ..................... ± 5 min / year
Program class .......................................................... A
Data storage without power supply ............................ min. 10 years
Technical characteristics - sensors
Temperature sensor type .......................................... Pt1000 or KTY10
Sensor resistance
Pt1000 ..................................................................... 1078 Ohm at 20 °C
KTY10 ...................................................................... 1900 Ohm at 20 °C
Temperature scope of use
Outdoor sensor AF ................................................... -25 ÷ 65 °C, IP32
Immersion sensor TF ................................................ -25 ÷ 150 °C, IP32
Surface sensor VF .................................................... 0 ÷ 85 °C, IP32
Gas exhaust sensor CF ............................................ 20 ÷ 350 °C, IP32
Min. cross-sectional area of sensor cables ................ 0.3 mm2
Max. length of sensor cables ..................................... max. 30 m
