Dimensional Drawings - Eneo VKC-1330IR12-24 Montage- Und Betriebsanleitung

Type
EDP No.
Camera mount
Supply voltage (±10%)
Power consumption
Temperature range
Dimensions
Colour
Weight
Parts supplied
Accessories
EDP No.
70771
70769
70697
43238
43237
45246
45249
45251
47156
47158
47157
47159
47154
47149
47148
47147
70448
77779

10. Dimensional Drawings

See Page 42
Downloaded from www.Manualslib.com
VKC-1330IR12-24
12VDC, 24VAC 50/60Hz
6 pin adapter cable with open ends, 4 pin lens plug, C mount adapter ring
Description
Wall Mount with Ball Joint
Wall Mount with Ball Joint
Wall Mount with Ball Joint
F1.0/3-8mm DC Lens/var. Focal Length
F1.4/2.8-11mm DC Lens/var. Focal Length
F1.3/2.7-13.5mm DC Varifocal Lens
F1.8/3.6-18mm DC Varifocal Lens
F1,6/5-50mm DC Varifocal Lens
F1.2/2.8mm Fixed Focal Length Lens
F1.2/6mm Fixed Focal Length Lens
F1.2/4mm Fixed Focal Length Lens
F1.2/8mm Fixed Focal Length Lens
F1.2/8mm DC Lens with No Focus Shift
F1.2/6mm DC Lens with No Focus Shift
F1.2/4mm DC Lens with No Focus Shift
F1.2/2.8mm DC Lens with No Focus Shift
Plug-in Power Supply 100-240VAC/12VDC
Plugable PSU 12VDC-500mA, stabilized
manuals search engine
91967
1/4" - 20 UNC thread on top and bottom
4.5watts max.
-10°C to +50°C
See drawing
Body: Pantone 877, Front and back: Pantone 8400C
265g
28
VKC-1330/IR
91968
230VAC, 50Hz
6.0watts max.
