Page EN-22 Start-up
Depending on the space conditions, you can
change the direction of the door hinges on
your appliance. This work, however, requires
you to have a certain degree of craftsmanship
skills. Please read the following steps com-
pletely before changing the hinges.
You will need the following tools to change
the door hinges:
– Medium size cross-tip screwdriver
– Medium size flat-headed screwdriver
Removing the glass door
1. Ensure that the appliance is not connect-
ed to the power supply.
2. Remove the bottle shelves (4).
(17)
3. Gently push the blanking plate (17) and
hinge cover (18) upwards with a slotted
screwdriver and remove them.
Hold onto the blanking plate and hinge cov-
er.
(19)
4. Ensure that the glass door cannot slip
away (1) and loosen the screws (19) on
the upper hinge (20). Use the cross-tip
screwdriver.
5. Remove the screws (19) and the upper
hinge (20). Keep hold of all the parts.
6. Lift off the glass door (1) and set it aside.
(18)
(20)
7. Remove the washer (21) from the lower
hinge (22).
(23)
8. Loosen the screws (23) and remove the
lower hinge (22) from the appliance.
9. Remove the screw foot (2) and screw it
back in on the opposite side.
(21)
(22)
(23)
(22)
(23)
(23)
(2)
