CHAIN
GEAR HUB WITH DISK BRAKE
1. Use a 5-mm Allen wrench to undo the two screws
on both sides of the frame
2. Use a 5-mm Allen wrench to undo the fixing screw
CD) on both sides.
3. Now shift the rear wheel to adjust the chain tension (
do so, screw in the fixing screw
has been reached. Make sure that the wheel is straight when
seated in the holder and that the chain is properly tensi-
oned (see Checking the chain tension chapter)
4. Tighten the screws
122
chapter).
EN EN 42
. until the correct position
123
+ firmly (see Torque specifications
125
+
122 125
(Fig.
2
). To
126
125
126
122
123
124
