Midland BTX2 FM Bedienungsanleitung Seite 20

› Phone (A2DP Stereo)
› GPS (A2DP Stereo)
› Dongle A2DP Stereo
When a device is paired to the "Vol +" or "Vol –" buttons the "Phone" mode is
activated.
Attention: A2DP audio source are supported only on Vol+. The second phone paired
on Vol- can support only mono audio (HFP).
Background feature
It is possible to keep always in background the audio of the device paired on
Vol- button. In this way the Intercom communication will not be interrupted, for
example, by the GPS's street indication or the G8BT radio communication.
To activate the "Background" feature just press long the "Vol-" button, the voice
"Background ON" will tell you that now is active.
To deactivate the "Background" feature just press again long the "Vol-" button,
the voice "Background disable" will tell you that now is not active anymore.
By default the "Background" feature is off.
Attention: we can't garantee this features because is depending on third part
device.
B-Phone mode
Mode Forward button (Phone on Vol+)
Phone Short press: Voice dial /accept or close if it
is in progress
Long press: redial last number/ or reject
Phone Short press: Forward the song
(when music is plaing
and paired on "Vol +")
› Phone (HFP Mono)
› GPS mono
› PMR446 Transceiver
Middle button
Long press: Change mode
Short press: Play/pause
Long press: Change mode
Pairing with one or two phone
The cellular phone can be paired to the "Vol +" (if the support for stereo A2DP is
requested) or to the "Vol –".
When a phone is paired to the "Vol +" or "Vol-" the "Phone" mode is activated.
An incoming call has always the higher priority, that means all other communica-
tions will be closed (Intercom, FM Radio, Music).
If another incoming call will arrive on the second phone, alert sound will notify it.
How to pair the BTX2 FM to a Phone
To pair the BTX2 FM to a Phone, you must first enter the setup mode:
1. Turn off the unit
2. Press and hold down the middle button about 7 sec., until the Red light is on
permanently.
3. Now press for 3 seconds the "Volume +" or "Volume -" button, the Blue and Red
light will flash.
4. Enable the Bluetooth device search feature on your mobile phone
5. After some seconds, "Midland BTX2 FM" will be displayed on your mobile phone.
Follow the pairing procedure of your Phone. If a pin code is requested you must
enter "0000" (four time zero).
When successfully paired, the Blue light of the unit will be on for one second and
than the unit will exit the setup mode and switch to the working mode (the Blue
light will start flashing).
You can use now your BTX2 FM together with the Phone.
How to use a Phone
After pairing your phone to the BTX2 FM unit you must switch to the "Phone" mode
in order to use it. Press the middle button until you hear "Phone" from the voice an-
nouncement. Now all the three main buttons are dedicated to the phone (see Table B)
Answering a call
When you hear the phone ring, you can answer in two different ways:
Vocally:
Simply say one word to answer the call and start talking.
Backward button (Phone on Vol-)
Short press: Voice dial /accept or close if it
is in progress
Long press: redial last number/ or reject
Short press: Backward the song
Midland BTX2 FM - 19
