5. Enter the following values under
Operating mode:
IP address:
Netmask

Configuring global network settings

Global network settings ensure that the web application is accessible from all sub-
networks, even in complex networks.
How to configure global network settings:
1. Select the section
Global settings
2. Enter the following values:
Operating mode:
In the DHCP operating mode the following settings are obtained automati-
cally. Making entries is not possible.
Hostname:
Domain:
Gateway:
DNS server 1:
DNS server 2:
3. Click on .
Save
NOTE: After successfully setting the IP address, integrate the target module into
the network of the IP matrix switch.
You can add the target module to the IP matrix switch using the
function of the IP matrix switch.
Establishing a KVM-over-IP™ connection for the first time
Transmission
Select the operating mode of the interface:
A static IP address is assigned.
 Off: Static:
 DHCP: Obtain IP address from a DHCP server.
Only if the Static operating mode is selected, enter the IP
address of the interface.
Only if the Static operating mode is selected, enter the net-
mask of the network.
.
Enter the desired operating mode:
Use of static settings.
 Static:
 DHCP: Obtain settings from a DHCP server.
Enter the hostname of the device.
Enter the domain to which the device should belong.
Enter the IP address of the gateway.
Enter the IP address of the DNS server.
Optionally, enter the IP address of another DNS server.
:
Add end devices
RemoteAccess-IP-CPU series · 19
