B

Configuration

Establishing a KVM-over-IP™
connection for the first time
G&D's KVM-over-IP™
target module and the IP matrix switch using a Gigabit Ethernet (layer 3).
NOTE:
The Transmission
sion between the target module and the IP matrix switch.
The Network interface is used exclusively for communication with the virtual com-
puters.
Only after the initial setup of the KVM-over-IP™ connection between the target
module and the IP matrix switch can the target module be used with the IP matrix
switch.
By default, the following settings of the Transmission interface are preselected:
 IP address of the Network interface:
Obtain address via
 global network settings:
Obtain settings via
Automatic initial setup
You can conveniently set up the
the IP matrix switch (see section Adding end devices in the manual of the web application
of the IP matrix switch).
NOTE: Manual configuration as described in the following section is not necessary
in this case.
Manual initial setup via direct connection
If you want to perform the initial setup manually, you can do this via the Target
module's own web application.
technology makes it possible to transmit signals between the
interface of the target module is used for signal transmis-
DHCP (Fallback: IP address:172.17.0.10)
DHCP
KVM-over-IP™ connection
via the web application of
RemoteAccess-IP-CPU series · 17
