Operation
7.2.2

Handling with steel-finger grippers (WB-SQ)

Before each start-up check all brackets for mobility, abrasion and contamination.
Worn (no longer sharp-edged) or bent brackets must be replaced! Otherwise the gripping god ncould fall down!
Danger to life!!!
1.) Position the device (FTZ-multi 15) centric over the
stone.
20 / 25
Fig. A
2.) Place the device on the gripping good (ashlar rock).
Then lift the device (FTZ-multi 15) with the gripped
gripping good just a little (20 cm).
V1
Fig. B
