Modster F-22 Raptor Handbuch Seite 17

Transmitter Instruction
One-key Aerobatics Button
One-key U-turn Activation
Throttle ↑↓
Not
Functional
One-key U-turn Switch
X-PILOT Stabilizer Switch
0 - Away From You- Weak Gyro Assit (EXPERT)
1 - At the Middle - Soft Gyro Assit (MIDD)
2 - Towards You - Strong Gyro Assit (BEGINNER)
Binding Instruction
Binding is the process of programming the receiver to recognize the
If you need to rebind for any reason, please follow these steps:
1.Keep the transmitter switched OFF, throttle joystick at buttom position.
NOTICE: Keep Gyro switch at Middle or Beginner position.
NOTICE: Keep the plane still in a calm environment for calculating the Gyro.
2.Connect the battery to the plane, then turn on the transmitter within 5 seconds.
Follow below steps when you operate a bound plane:
2.Connect the battery to the plane within 3 seconds.
LED Indicator
17 / 24
The F-22 comes with X-PILOT stabilizer
is with 3 levels to control the stabilizer.
Needing more X-PILOT assist, switch
to upper position(towards you). To gain
more manual control, switch to lower
position(away from you).
X-PILOT Switch
Elevator Trimmer Elevator Trimmer
Elevator ↑↓ Elevator ↑↓
Aileron ←→ Aileron ←→
Aileron Trimmer
ON/OFF Switch
