Modster F-22 Raptor Handbuch Seite 16

Center Control Surfaces
surfaces.
With the battery conected to the airplane, it is now possible to check the center of all
control surfaces.
Observe the hinges to ensure it is properly centered as shown on the right.
Not centered
Push Rod Arc-shaped
Section
3. Connect the battery to the receiver,
then insert the battery into the bottom of
fuselage. Secure the battery hatch.
adjust the push rod by its arc-shaped
section slightly, making sure the hinges
are properly centered.
16 / 24
Centered
