SETTINGS
PRESETTINGS
PUSH LEFT
(KEEP PUSHED)
RESETTING TO
FACTORY VALUES
TEST
(MONITORING)
OUTPUT
CONFIGURATION
OUTPUT
REDIRECTION
NUMBER OF
CURTAINS
IMMUNITY FILTER*
PULSE FREQUENCY
MAX. PRESENCE
TIME
* In immunity 2 and 3, the standard detection capability is the same as in immunity 1 (factory setting). Environmental and installation conditions can
affect the detection capability of the sensor or can impact the availability of the door system. During harsh conditions, the sensor can temporarily
adapt the detection capability to ensure the availability of the door system.
4
SETUP
(step out of the detection field during setup)
QUICK SETUP =
:
IMPORTANT
Test the good functioning of the installation before leaving the premises.
(by push buttons and/or remote control)
3x GREEN LED
STANDARD
CRITICAL ENVIRONMENT
SHOPPING STREET
PUSH
LEFT + RIGHT
off on
A-P
safety
safety +
opening
service
1
mode
normal
medium
freq A
30 1 2
s min
FACTORY VALUES
OFF
RED-GREEN
RED-GREEN
>
OR
1
auto = the sensor will automatically adapt to the door controller:
auto
when the door controller monitors the sensor > on
when the door controller does not monitor the sensor > off
A = active output (NO-contact)
P-A P-P A-A
P = passive output (NC-contact)
0 presence detection on safety input
1 presence detection on safety and opening input
service mode = no detection is active during 15 minutes (maintenance).
2
> >
high
freq B
5 10 20
min min min min
excludes DIN18650-conformity of the door system
ASSISTED SETUP =
>
PUSH RIGHT UNTIL
RED-GREEN
FLASHES
RELEASE AFTER
FLASH OF DESIRED
SETTING
immunity 3 is only suitable if a combined
> >
sensor is on each side of the door
freq A+ freq B+
60
min
+
OPEN+CLOSE
RED-GREEN
OR
RED-GREEN OFF
PRESETTING
SELECTED
(excludes DIN18650-conformity)
Opening
Safety
OFF
