7.3 Specific adapter installation (TYPE A)
1. Remove the heatsink of the H7 LED bulb.
Attach it to the adapter.
7.4 Specific adapter installation (TYPE B)
1. Remove the heatsink of the H7 LED bulb.
Attach it to the adapter.
7.5 Specific adapter installation (TYPE C)
1. Remove the heatsink of the H7 LED bulb.
Attach it to the adapter.
2. Pull the cable through the adapter. At-
tach the adapter to the lamp housing (it
may be placed on a reflector). Attach the
heatsink (extension pole may be required).
Make sure the heatsink and the LED bulb
are properly fastened together.
2. Pull the cable through the adapter. At-
tach the adapter to the lamp housing (it
may be placed on a reflector). Attach the
heatsink (extension pole may be required).
Make sure the heatsink and the LED bulb
are properly fastened together.
2. Pull the cable through the adapter. At-
tach the adapter to the lamp housing (it
may be placed on a reflector). Attach the
heatsink (extension pole may be required).
Make sure the heatsink and the LED bulb
are properly fastened together.
13 |
