M-tech LED SET Montageanleitung Seite 11

4 HIGH/LOW BEAM KIT (H4, H13, HB1, HB5)
4.1 Outside heat sink installation
1. Twist the bracket anticlock-
wise to take off the LED bulb
base and fit the bulb into the
socket.
4.2 Inside lamp housing installation
1. Twist the bracket anticlock-
wise to take off the LED bulb
base and fit the bulb into the
socket.
5 SINGLE BEAM (H11, 9005, 9006, 5202)
5.1 Outside heat sink installation
1. Replace the original bulb with
the M-Tech LED bulb.
5.2 Inside heat sink installation
1. Replace the original bulb with
the M-Tech LED bulb.
2. Mount the dust cover and put back
the LED bulb base. Twist it clockwise and
make sure the LED bulb is fitted properly.
2. Put back the LED bulb base. Twist it
clockwise and make sure the LED bulb
is fitted properly. Connect to the original
plug.
2. Connect to the original plug. Use a zip-
tie or double-sided tape to mount the
control box.
2. Connect to the original plug. Use a
proper double-sided tape to install the
control box. Put the dust cover back on.
3. Connect to the original plug. Use a
zip-tie or double-sided tape to mount
the control box.
3. Use a proper double-sided tape to
mount the control box. Put the cover
back on.
