Assembly instructions
J-10 and Eurofighter
Recommended Equipment
#
Power set 6Blade Funnystar / Jets
1-01913
1
Servo MS8510 MG Digital
1-01724
3
Receiver RX-5 slim M-Link 2,4 GHZ
1-01190
1
852727
1
Zacki ELAPOR 20g
1-01032
1
Zackivator - Kicker for CA adhesives
1-00017
ROXXY EVO LiPo 3 - 350B 30C
1
Important info before you start assembling
Use the list of components on page 8 and 9 to check the completeness of the components supplied.
We recommend assembling the model on a clean and perfectly flat surface to ensure that the structure is free of warps and that the
components are not damaged during assembly. Be sure to cover the surface with clear plastic film to avoid the components sticking to
the surface.
Joints between EPP components are best made using UHU® POR. In this case, apply a thin film of adhesive to both surfaces to be
glued. Then allow it to air-dry for about ten minutes. Then press the parts together. The strength of the joint is determined by the pres-
sure you exert, rather than the length of time you exert it. When CFRP section rods have to be inserted into EPP parts, press the section
rods into the appropriate slot, then trickle low-viscosity (thin) Zacki-ELAPOR® super liquid onto them. A small amount of activator spray
will help to harden the adhesive. All other glued joints can be made using standard Zacki-ELAPOR®.
Some carbon rods are supplied cut to length. Although the rods are supplied cut to length, you may need to trim them slightly. Therefore,
make sure the carbon rods are the correct length before gluing them into place.
Many carbon rods have not been cut to length. For each assembly stage, it is then specified how many of these rods are to be used and
still have to be cut to length. These rods are numbered. We recommend that you hold the carbon rod in position, and cut it to length
using pliers or side-cutters. The kit includes an ample supply of carbon rods.
These written instructions are intended only as a supplement to the illustrations. All briefly described assembly steps are explained in
more detail there.
Preparing the individual components
To ensure the rudders move freely when the model is flying, fold all rudder flaps through 180° prior to assembly. Then leave them in this
position for about an hour
12
Anleitung Jets Final.indd 12
Required tool
• Small cross-tip screwdriver
• Small slotted screwdriver
Cutter
•
Cutter
•
Pointed pliers
Pointed pliers
•
1mm drill bit
1mm drill bit
