6.3. Motor overload protection

All safety-relevant functions are implemented by the hybrid motor starter, without external influences.
Special circuit technology is not necessary.
Wiring of the load current circuit should be realized as described in the examples provided. The module
current supply can however be directly connected to the voltage source, without the PSR safety relay. The
same is applicable for the control.
6.4. Motor with brake
If a motor with brake is connected (in the motor terminal board), the 400 V AC brake has to be connected
to the 2/T1 and 6/T3 connections. A 230 V AC brake must be connected with 4/T2 and the neutral point
of the motor.
Please note: The motor current monitoring must be increased by the value of the brake (nominal
brake current), (see item 5.3, page 20).

7. Technical data

Type
Input data
Rated control supply voltage U
Control supply voltage range
Control supply voltage
Rated control supply current as per IEC 60947-1
Control input L, R:
Output data
Switching principle
Rated operating voltage U
Operating voltage range
Load current at 20 °C (see 9.2. Derating curve).
Rated operating current I
AC-51
AC-53a
(see 9.2. Derating curve).
Nominal switching power
Full load (power factor = 0.4)
Leakage current (input, output)
Residual voltage at I
e
Surge current
Order No. ELR H51-IESSC-24DC500AC-06
s
as per IEC 60947-1 / UL 508 24 V DC
Switching level "Safe off" < 5 V DC
Switching level "Low" -3 ... 9.6 V DC
Switching level "Safe off" < 5 V DC
Switching level "High" 19.2 ... 30 V DC
Input current ≤ 3 mA
Load side ELR...-06
as per IEC 60947-1 500 V AC (50/60 Hz)
e
as per IEC 60947-1
as per UL 508
as per IEC 60947-1
e
as per IEC 60947-4-3
as per IEC 60947-4-2
as per UL 508
as per UL 508
Full load (power factor = 0.8)
ELR H51-IESSC-24DC500AC-2
ELR H51-IESSC-24DC500AC-9
19.2 ... 30 V DC
(32 V DC, max. 1 min.)
≤ 40 mA
ELR...-2
Safety output module with bypass, three-phase
electrically isolated shutdown
42...550 V AC
42...500 V AC
0.075...0.6 A 0.18...2.4 A
0.6 A 2.4 A
0.6 A 2.4 A
0.6 A 2.4 A
0.3 kW (0.4 HP) 0.9 kW (1.2 HP)
0.5 kW (0.6 HP) 1.7 kW (2.2 HP)
0 mA 0 mA
< 300 mV < 400 mV
100 A (t = 10 ms)
2902746
2902744
2902745
ELR...-9
1.2... 9.0 A
9 A
6.5 A
6.5 A
2.3 kW (3.0 HP)
4.6 kW (6.1 HP)
0 mA
< 600 mV
