TECHNICAL DATA
TECNISCHE DATEN CARACTERISTIQUES TECHNIQUES DATOS TÉCNICOS DATI TECNICI DADOS TÉCNICOS TEKNISKE DATA
1
CONNECTORS
ANSCHLÜSSE
A
A
Audio out
A
Audio in
red
red
phono
phono
white
white
phono
phono
B
Computer VGA 2
R/Pr
15 HIGH DENSITY DSUB
FEMALE
STEM RED: R/Pr
1 Analog R in
SHIELD: GND
2 Analog G in
3 Analog B in
4 AGND
5 AGND
6 Analog R GND in
7 Analog G GND in
8 Analog B GND in
9 Reserved
10 Sync GND in
STEM: H SYNC
11 AGND
12 DDC/SDA
SHIELD: GND
13 HSync in
14 VSync in
15 DDC/SCL
CONNECTEURS
B
Remote
S-video
4 PIN MINIDIN
2.5 mm
FEMALE
JACK
1 GND
TIP: right
2 GND
RING: left
3 Luma
STEM: common
4 Chroma
Video
PHONO/RCA
FEMALE
STEM: composite
SHIELD:GND
G/Y
B/Pb
STEM GREEN: G/Y
STEM BLUE: B/Pb
SHIELD: GND
SHIELD: GND
H
V
STEM: V SYNC
SHIELD: GND
CONECTORES
CONNETORI
B
Monitor
RS-232
15 HIGH DENSITY DSUB
9 PINS DSUB MALE
FEMALE
1 Analog R in
1 NC
2 Analog G in
2 RXD
3 Analog B in
3 TXD
4 NC (not connected)
4 NC
5 AGND
5 Gnd
6 Analog R GND in
6 NC
7 Analog G GND in
7 RTS (fixed - 5V)
8 Analog B GND in
8 Not used
9 Reserved
10 Sync GND in
11 NC
12 NC
13 HSync in
14 VSync in
15 NC
Audio in
Computer DVI
3.5 mm
1 TMDS Data 2-
JACK
2 TMDS Data 2+
3 TMDS Data 2/4 Shield
TIP: right
4 Not used
RING: left
5 Not used
STEM: common
6 DDC Clock
7 DDC Data
8 NC
9 TMDS Data 1-
Audio in
10 TDMS Data 1+
11 TMDS Data 1/3 Shield
12 Not used
3.5 mm
13 Not used
JACK
14 +5V Power
15 Ground (+5, Analog H/V Sync.)
TIP: right
16 Hot Plug Detect
RING: left
STEM: common
17 TMDS Data 0-
18 TMDS Data 0+
19 TMDS Data 0/5 Shield
20 Not used
21 Not used
22 TMDS Clock Shield
23 TMDS Clock+
24 TMDS Clock-ss
1
31
CONECTORES
KONTAKTER
Audio in
Computer VGA 1
3.5 mm
15 HIGH DENSITY DSUB
JACK
FEMALE
TIP: right
1 Analog R in
RING: left
2 Analog G in
STEM: common
3 Analog B in
4 AGND
5 AGND
6 Analog R GND in
Audio in
7 Analog G GND in
8 Analog B GND in
9 Reserved
10 Sync GND in
3.5 mm
11 AGND
JACK
12 DDC/SDA
TIP: right
13 HSync in
RING: left
14 VSync in
STEM: common
15 DDC/SCL
PS2
Ethernet
USB
6 PIN MINIDIN
DIGITAL
1 TX+
FEMALE
USB
2 TX-
3 RX+
1 Data
1 VCC
4 Not used
2 Noy used
2 -Data
5 Not used
3 GND
3 +Data
6 RX-
4 Power,
4 GND
7 Not used
+5 VDC
8 Not used
5 Clock
6 Not used
Mouse
Lan
