MS-7028 ATX Mainboard
Parallel Port IRQ
This item allows you to set parallel port IRQ. Setting options: [IRQ5], [IRQ7].
SATA Devices Configuration
Press <Enter> to enter the sub-menu and the following screen appears:
ATA/IDE Configuration, Configure SATA as
These 2 items allow you to select the ATA/IDE and SATA configuration. Select [Disabled]
in ATA/IDE Configuration if you want to disable both ATA/IDE configuration. Select
[Compatible] or [Enhanced] to use the IDE, S-ATA and P-ATA devices. Refer to the
following tables for details.
For the setting options of Configure SATA as, select [IDE] if you want to have SATA
as IDE function. Select [AHCI] to allow the SATA having Advanced Host Controller
Interface (AHCI) feature, which supports improved serial ATA disk performance with
native command queuing & native hot plug. Select [RAID] to use SATA as RAID
function. Setting options: [IDE], [AHCI], [RAID].
E-3-8
Downloaded from
www.Manualslib.com
SATA Only
PATA Pri, SATA Sec
SATA Pri, PATA Sec
PATA Only
IDE
AHCI
RAID
manuals search engine
ATA/IDE Configuration
(Compatible)
[SATA 1/3/2/4]
[IDE1, SATA2/4]
[SATA1/3, IDE1]
[IDE1]
ATA/IDE Configuration
(Enhanced)
[IDE1, SATA 1/2/3/4]
[IDE1, SATA 1/2/3/4]
[IDE1, SATA 1/2/3/4],
[SATA support RAID 0 or 1]
