MS-7028 ATX Mainboard
11. Push down the CPU hardly to install
13. Press down the load lever lightly
15. Press the four hooks down to fas-
E-2-6
Downloaded from
www.Manualslib.com
the CPU into the socket housing
frame.
onto the load plate, and then se-
cure the lever with the hook under
retention tab.
ten the cooler. Then rotate the lock-
ing switch (refer to the correct di-
rection marked on it) to lock the
hooks.
locking
switch
MSI Reminds You...
1. Whenever CPU is not installed, always protect your CPU socket pin
with the plastic cap covered (shown in Figure 1) to avoid damaging.
2. Please note that the mating/unmating durability of the CPU is 20 cycles.
Therefore we suggest you do not plug/unplug the CPU too often.
manuals search engine
12. Visually inspect if the CPU is seated
well into the socket, then remove the
CPU Clip with 2 fingers. Then cover
the load plate onto the package.
14. Align the holes on the mainboard with
the cooler. Push down the cooler until
its four clips get wedged into the holes
of the mainboard.
16. Turn over the mainboard to confirm
that the clip-ends are correctly
inserted.
