VIA6410 IDE Raid Controller (Optional)
Two Ultra DMA 66/100/133 IDE Controllers.
Supports RAID 0, 1 and 0+1.
Connect up to 4 Ultra ATA 133 devices.
On-Board Peripherals
On-Board Peripherals include:
- 1 floppy port supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 1 serial port
- 1 VGA port (for 915G only, Optional)
- 1 parallel port supports SPP/EPP/ECP mode
- 1 Line-In / Line-Out / MIC-In / Rear Speaker Out / Center-Subwoofer Speaker Out
- 8 USB ports (Rear * 4/ Front * 4)
- 1 RJ-45 LAN jack
- 3 IEEE 1394 connectors (Optional)
LAN
Realtek
- Integrated Fast Ethernet MAC and PHY in one chip.
- Supports 10Mb/s, 100Mb/s and 1000Mb/s (1000Mb/s for 8110S only).
- Compliance with PCI 2.2.
- Supports ACPI Power Management.
Marvell 8053 (Optional)
- PCI Express bus Spec 1.0a compliant.
- X1 PCI Express interface with 2.5 GHz signaling.
- 10/100/1000 IEEE 802.3 compliant.
Audio
Azalia link controller integrated in Intel
8-channel audio codec CMI9880L.
- Compliant with Azalia 1.0 Spec.
- Supports Multi-Streaming function.
- Supports Universal Audio Jack (only Front Audio Jack).
BIOS
The mainboard BIOS provides "Plug & Play" BIOS which detects the peripheral
devices and expansion cards of the board automatically.
The mainboard provides a Desktop Management Interface (DMI) function which
records your mainboard specifications.
Mounting and Dimension
ATX Form Factor: 24.4 cm (W) x 30.5 cm (L)
9 mounting holes
Downloaded from
www.Manualslib.com
/ SPDIF-Out optical and coaxial audio port
®
8100C / 8110S (Optional)
manuals search engine
®
ICH6/ICH6R chipset.
Getting Started
E-1-5
