memory size up to 4GB.
ard is not backward compatible, you should always install DDR2 memory module in
the DDR2 slot (DIMM1~DIMM4). Otherwise, you are not able to boot up your system
and your mainboard might be damaged.
com.tw/program/products/mainboard/mbd/pro_mbd_trp_list.php.
Introduction to DDR2 SDRAM
current DDR1 technology. DDR2 uses a 1.8V supply for core and I/O voltage, com-
pared to 2.5V for DDR1, and requires 28% less power than DDR1 chips. DDR2 truly
is the future of memory, but will require some changes as the technology is not
backwardly compatible and only motherboards specifically designed for DDR2 memory
will be able to support these chips.
integrity, thereby enabling higher clock speeds.
length of DDR2 module is 5.25". DDR2 modules have smaller and tighter spaced pins.
The height of DDR2 modules varies, but they will typically be less than 1.3" in height.
Downloaded from
www.Manualslib.com
The mainboard provides 4 slots for 240-pin DDR2 DIMM, which supports the
Since DDR2 modules are not interchangeable with DDR1 and the DDR2 stand-
For the updated supporting memory modules, please visit http://www.msi.
DDR2 is a new technology of memory module, and its speed is the top limit of
DDR2 incorporates new features at the chip level that give it better signal
DDR2 modules have 240 pins, versus 184 pins on a DDR1 module, and the
manuals search engine
Memory
DIMM1~DIMM4
(from left to right)
Channel A (DIMM1, DIMM2): Green
Channel B (DIMM3, DIMM4): Orange
Hardware Setup
E-2-7
