MS-7028 ATX Mainboard
Mouse
Keyboard
Mouse/Keyboard Connector
for attaching a PS/2
into this connector. The connector location and pin assignments are as follows:
PS/2 Mouse / Keyboard
VGA Connector (Optional)
monitor.
E-2-10
Downloaded from
www.Manualslib.com
The back panel provides the following connectors:
Parallel
COM A
The mainboard provides a standard PS/2
®
mouse/keyboard. You can plug a PS/2
6
5
3
4
1
2
(6-pin Female)
The mainboard provides a DB 15-pin female connector to connect a VGA
5
1
11
15
VGA Connector
(DB 15-pin)
manuals search engine
Back Panel
S/PDIF
VGA port
USB Ports
(Optional)
®
mouse/keyboard mini DIN connector
Pin Definition
PIN
SIGNAL
1
Mouse/Keyboard Data
2
NC
3
GND
4
VCC
5
Mouse/Keyboard Clock
6
NC
Pin
Signal Description Pin
1
RED
3
BLUE
5
GND
7
GND
9
+5V
11
N/C
13
Horizontal Sync
15
SCL
RS-Out
L-In
LAN
CS-Out
L-Out
Mic
SPDIF Out
®
mouse/keyboard directly
DESCRIPTION
Mouse/Keyboard data
No connection
Ground
+5V
Mouse/Keyboard clock
No connection
Signal Description
2
GREEN
4
N/C
6
GND
8
GND
10
GND
12
SDA
14
Vertical Sync
