FIG. 1 FC410DIM Modulo d'ingresso per rivelatori convenzionali
FC410DIM Detector Interface Module
FC Adapter fur Konventionelle Melder - FC410DIM
L+ L- L+ L- COM +24
TB1
PORTA DI PROGRAMMAZIONE
PROGRAMMING PORT
PROGRAMMIERANSCHLUSS
FIG. 2 FC410DIM fissata al coperchio
FC410DIM fitted to cover
FC410DIM ins Gehäuse eingebaut
+L1
LEFT
-L1
CENTRALE FC
FC CONTROLLER
FIG. 4 Circuito SPUR (Classe B)
'Spur Circuit' (Class B)
Stich-Verdrahtung
A+ A- B+ B-
TB2
TB3
PORTA DI PROGRAMMAZIONE
PROG PORT
PROGRAMMIERSTECKER
PORTA DI PROGRAMMAZIONE
ADDRESS SETTING PORT
PROGRAMMIERANSCHLUSS
FIG. 3 FC410DIM Placca
Facia Plate
Kurzschlussisolator Vorderseite
ALIMENTATORE ESTERNO 24 Vcc
EXTERNAL POWER SUPPLY 24V d.c.
EXTERNE ENERGIEVERSORGUNG 24 VDC
AL DISPOSITIVO SEGUENTE
TO NEXT DEVICE
ZUM NÄCHSTEN ELEMENT
