3. Dismantling the Caddy
Locking device
Carry on handle
Lower bag support
3.1. Turning off the Caddy
Press gently on the light/LED, it is turned OFF when the light is off.
3.2. Collapsing the front wheel and opening the locking device
Before opening the locking device please remove the golf bag and push the handle into
park position. Than press the locking button and turn the front wheel into the shown
position.
Now open the handle locking device by pulling it towards you. The handle bar can
now easily be moved, and the Caddy can be collapsed.
3.3. Collapsing the Caddy
Place the Caddy vertically on its lower Bag support. Now hold the Caddy's carry beam
and move the handle bar down. Both side arms, with the wheels, will flap towards the
frame. Make sure that the handle bar can be easly moved and that the side wheels
are up in the air. As soon as the handle bar is nearly in parallel to the main frame, the
Caddy is completely collapsed.
Locking button
