1. Bottom of the charging/Repeater station
2. Mains adapter
• Put the cradle feet as shown below on the charger bottom:
- For wall mounting you have to use '
- For desktop charging you have to use '
Downloaded from www.Manualslib.com
2
'
'
manuals search engine

2.2.1 Wall mounting

The charging/Repeater station can be wall mounted as shown on
the picture below.
The drilling holes need to be drilled horizontally 3 cm from each
other:
9
