Specification

Measurement range
Resolution
Accuracy
Reproducibility
Storage
Storage Interval
Over-range display
Display-update
Environmental conditions
Display
Supply
Dimensions
Weight
Standards

Delivery contents

1 x Lux-measuring device PCE-174, 1 x light sensor, 1 x software, 1 x USB-cable, 1 x battery,
1 x device case, 1 x operating manual
4

System description

Downloaded from www.Manualslib.com manuals search engine
Manual
400.0 / 4000 / lux
40.00 / 400.0 klux
40.00 / 400.0 / 4000 / fc
40.00 kfc
0.1 / 1 / 10 / 100 lux
0.01 / 0.1 / 1 / 10 FootCandle
± 5% of measurement value ± 10 digits (<10,000 lux)
± 10% of measurement value ± 10 digits (>10,000 lux)
± 3 %
16,000 values
Between 2 and 99 seconds
OL= overload
1.5 per second
0 ... 40°C / 80% RH
3¾ digits LCD-display
9 V block battery
Device: 203 x 75 x 50 mm (W x H x D)
Light sensor : 115 x 60 x 20mm (W x H x D)
Cable length: 150 cm
280g
Safety: IEC- 1010- 1; EN 61010- 1
EMV: EN 50081- 1; EN 50082- 1 DIN
5031 ; DIN 5032
1. On/Off key
2. Display: 3¾ digits display
3. UNITS key: Press this key to switch to the
measuring mode for footcandle (1 fc= 10.76 lux)
4. Backlight: Turn on and off
5. REC/SET key
6. PEAK key: Press this key to activate the peak
value display.
7. HOLD key: The current value on the screen is
frozen.
8. Range key: Press this key to select between
different measurement ranges (e. g. 400.0/4000
lux).
9. MAX/MIN key: Press this key to select the
maximum and minimum value.
10. REL key: Press this key to switch to
comparative readings (zeroing).
