6. Operation

For all works on the appliance, pull the mains plug out
of the socket.
Switch symbol on the appliance:
0 = OFF
I = ON
= Radio remote control
Always use the appropriate filters for the
appliance.
Test the appliance for damage before each
operation.
Remote control layout (Fig. 30):
Set the switch on the appliance to "radio remote
control".
Press the "reset" button on the side of the head
for 15 seconds, e.g. with a pencil point, until the
display is lit up.
At the same time press down the "0" or "I" switch
on the remote control for 15 seconds.
After the display flashed 3 times, the remote
control is set.
6.1 Dry vacuuming (Fig. 15 - 22)
Use the pleated filter (11) and dirt bag (15) for dry
vacuuming.
Remove the operating head (C) from the bin (D).
Attach the pleated filter (11).
Before dry operation, make sure the pleated filter
is securely attached. Please note that the filter
should be pushed onto on the operating head up
to the stop. (Fig. 19)
Attach the filter holder (12) onto the pleated filter
and lock it by pressing it and turning it clockwise
at the same time.
When vacuuming fine dirt, use the dirt bag (15) in
addition inside the bin. This will ensure that the
pleated filter does not fill up too quickly and
therefore helps the vacuuming power last longer.
In addition, it makes it easier to dispose of the
dust. Slip the dirt bag over the vacuuming hole.
The dirt bag is suitable for dry-vacuuming only.
Set the operating head back onto the bin and
close it with the fastening lug.
Switch the appliance ON by moving the switch to
position "I". When using the remote control,
change the switch to the "radio" position. The wet
and dry vacuum cleaner will now be switched ON
and OFF at the handle (19) with the remote
control if you press down the "ON" switch on the
16.07.2010 11:40 Uhr Seite 17
remote control down for 1 second.
To switch the wet and dry vacuum cleaner OFF,
move the switch to position "0" or press down the
"OFF" button on the remote control for one
second.
6.2 Wet vacuuming (Fig. 6, 23-24)
Caution: When vacuuming larger amounts of
fluid, we recommend removing the wet and dry
vacuum cleaner from the wall mount and place it
on the floor. If the appliance is full of fluid, it will
be more difficult to lift the vacuum cleaner out of
the wall mount. The pleated filter cartridge may
not be used for wet vacuuming. Protect the
remote control from moisture.
Remove the operating head (C) from the bin.
Remove the pleated filter (11) and attach the
foam filter (16) to the filter cage. Attach the
operating head back onto the bin.
Switch the appliance off after wet vacuuming and
remove the mains plug from the electrical supply.
Clean the bin. Remove the foam filter, clean it
with liquid soap and leave it to dry before storing
the appliance.
When extracting larger amounts of fluid, the nozzle
should not be fully immersed in the fluid. Leave a gap
in the tip of the nozzle so that additional air can be
taken in. The appliance is fitted with a float which
prevents overflow of the bin. If the appliance stops
vacuuming, you will notice an increase in motor
speed (if the motor is "whining"). If this happens,
switch the appliance off immediately, disconnect it
from the power supply and remove the fluid. In order
to start vacuuming again, attach the operating head
back onto the bin.
6.3 Blasting function (Fig. 3, 25)
Make sure the bin is empty.
Remove the exhaust air diffuser from the blower
connection.
Remove the suction hose from the suction
connection and attach it to the blower connection
Attach the desired accessory to the suction hose.
Important: Do not direct the air flow at persons.
6.4 Replacing the battery (Fig. 26-29)
Use 23AE 12 V batteries.
If you do not use the remote control over longer
periods of time, please remove the batteries from
the battery compartment. Leakage of battery fluid
could damage the appliance.
Do not put batteries on heaters or expose them to
direct sunlight for long periods of time.
Loosen the screw in a clockwise direction.
Remove the screw and take the old battery out.
