Presets / Sounds - Studiologic numaconcert Bedienungsanleitung

Pitch
• Picth bend of ±2 semi tones
MIDI Module
Program Change
Bank Select LSB
Bank Select MSB
On / O
Channel
Octave
Volume EDIT Zone
Display - Value +/-
• Preset recall
Press and hold Demo for a few seconds to play the demo
songs. They will start automatically and DEM is shown in the
display. Use Value +/- to play the next or previous demo song.
By pressing Demo again you quit the demo mode.
As long as the instrument displays P followed by a two
digit number (eg P05) you can recall any preset by pressing
Value +/-. There are 24 factory presets available (P01 – P24).
The sound engine can be activated or deactivated using the
On/Off button.
To select a sound, use the 12 labelled buttons. The button of
the selected sound lights up.
To adjust the sound of the instrument to the environment,
you can cut or boost low and high frequencies using the Bass
and Treble knobs in the Output section. Set the sound level
with the Volume knob.
If you have to play in a different key, you can simplify this task
by transposing the keyboard (eg: from F plus one semitone
to F sharp).
To transpose in steps of a semi-tone, press Function &
Transpose. Use Value +/- to change the transposition. If no
transposition is used, 0 will be displayed. Adjustments of -6
to 5 semi-tones can be processed, to cover the entire range.
Press Function again to keep the adjustment and quit
transposition mode. The Transposition setting will be kept
until the instrument power is switched off.
To temporarely vary the pitch while playing by ±2 semitones,
use the Pitch wheel on the left. The wheel is self centering
and will go back to its center position after being released (ie,
no pitch applied).
Downloaded from www.Manualslib.com
On/Off - Demo
• Sound engine on/off
• Play Demo-songs
MIDI Module Sound Bank
[ Dem o]
Transpose Octave Lower Octave Upper Master Tune
Program Change
Bank Select LSB
Bank Select MSB
On / O
On / O Concert GrandStage Grand
Channel
Preset / Value Preset / Value
Panic Hold
Octave
Volume EDIT Zone A-Lower B-Upper
A-Lower B-Upper Split Point Function Pad 1 Pad 2
Function
• in combination with
Transpose
and
manuals search engine
Sound Bank
• Direct access to the 12
internal sounds
Sound Bank
Modulation
[ D em o] Velocity Transpose Strings Res Octave Lower Octave Upper Master Tune Velocity
Chorus
Phaser
On / O Concert GrandStage Grand E Piano 1 E Piano 2 E Piano 3
E Piano 1 E Piano 2 E Piano 3 Clavi
Rotary
Expression Free Wheel System Panic Store Hold Expression Free Wheel System
Tremolo
Min Max
Split Point Function Pad 1 Pad 2 Organ 1 Organ 2 Bass 1
Organ 1 Organ 2 Bass 1 Bass 2 Select Assign Amount
Transpose
Demo • Transposition of the key-
board to other tunes

Presets / Sounds

Bass / Treble
• EQ: Cut / boost of low and
high frequencies
E ects E ects Output
Reverb
Modulation Reverb
0 0
Strings Res
Chorus
Room Phaser Room
Min Max Min Max
Clavi
Bass Treble
Hall Rotary Hall
50% 0 50%
Store
Delay Tremolo Delay
Min Max Dry Wet
Dry Wet Lower Upper
Bass 2 Select Assign Amount Select Assign Mix
Select Assign Mix Balance Volume
Volume
• Sound level
Demo songs
Preset recall
Sound engine /
Sound selection
EQ / Volume
Transpose
Pitch wheel
NUMA Concert by Studiologic®
Output
0 0
Min Max Min Max
Bass Treble
0
Lower Upper
Balance Volume Fatar Touch
Fatar Touch
