The Pause/Resume (+) button stops values from automatically
updating to allow for closer examination of the relationship
between the values or to allow time to manually record the entire
dataset. Press (+) again to resume.
Gage functions are menu controlled. To access the Menu, power-
up the gage, then press the center navigation button.
Center
Down
NOTE:
eliminate unintentional powering-up of the gage.
To disconnect a probe from a body, power-down the
instrument and pull the plastic probe connector
horizontally (in the direction of the arrow) away from the
body. Reverse these steps to attach a new probe.
When powered-up the PosiTector automatically
determines which probe is attached and does a
self-check.
Additionally, the PosiTector accepts a number of probe types
including magnetic and eddy current coating thickness, surface
profile, environmental and ultrasonic wall thickness probes.
For the latest information on probe interchangeability, see
www.defelsko.com/probes
Downloaded from www.Manualslib.com

Menu Operation

Menu Operation
Navigation Button
To navigate, use the Up and Down buttons to
Up
scroll and
Select Exit to exit from any menu.
The center
manuals search engine
to SELECT.
button is purposely recessed to help
Probes
Probes
