Control Board

The Control Board offers several features: you can easily set the starting address or run the pre-
programmed program.
MODE UP
MODE
d001
F001
A001
CFXX
CCXX
CSXX
r000
G000
b000
U000
dEMo
Soun
dEL0
OLSS
Wireless Setting
From factory, this device is prepared for wireless data transmission (WDMX). If you wish to de-activate
WDMX control, you can select the function "OLSS" – "oFF". With the function "OLSS" – "oN" you can
activate WDMX control, the fixture can now receive the wireless DMX signal.

DMX Mode

You can control the device individually via your DMX-controller. Every DMX-channel has a different
occupation with different features. The individual channels and their features are listed under DMX-protocol.
The device has three DMX modes. The Control Board allows you, as described above, to assign the desired
DMX mode.
Downloaded from www.Manualslib.com
Browse through the main menu by pressing the UP or DOWN buttons. You can
browse through the submenu and confirm your choice by pressing ENTER.
You can change the selection by pressing UP or DOWN. You can leave every
mode by pressing MODE.
DOWN ENTER
The functions provided are described in the following sections.
VALUE / SUBPROGRAM
001 - 512
001 - 512
001 - 512
00 - 99
00 - 99
00 - 99
000 - 255
000 - 255
000 - 255
000 - 255
--
--
dEL0
dEL1
dEL2
dEL3
oN
oFF
manuals search engine
FUNCTION
DMX address setting 4-Channel-Mode
DMX address setting 5-Channel -Mode
DMX address setting 8-Channel -Mode
Color fade with increasing speed (Master-mode)
Color change with increasing speed (Master-mode)
Color presets (Master-mode)
Manual Dimmer: Red
Manual Dimmer: Green
Manual Dimmer: Blue
Manual Dimmer: White
Auto mode (Master-Mode)
Sound controlled mode (Master mode)
Neutral
Dimmer speed 1
Dimmer speed (step response)
Dimmer speed 2
Dimmer speed 3
Wireless on
Wireless off
