If you have installed Rekid in the back seat you can now move the front seat to a
comfortable position.
Note: The back of the child restraint may, but does not need to be in contact with
the back of the front seat.
Placing your child in the seat
Press the harness adjuster button (E) and pull forward on the shoulder straps (not
17
the shoulder pads) to completely loosen the harness.
18
Press the red harness release button on the buckle and unfasten the harness.
Place your child in the car seat. Put your child's arms in between the shoulder
19
straps so that the straps are hanging over the chest and stomach.
Pull the shoulder straps together and insert the harness tongues into the
20
crotch buckle.
Pull the harness adjustment strap (F). It's important that you always pull the
21
harness straight and central when you tighten the adjustment strap. This will
tighten the harness and the headrest will automatically slide down to the
appropriate height.
Head support brake on headrest
The headrest on your Rekid is equipped with a head support brake. This can be
22
used if you want to keep the headrest in a fixed position. To activate the head
support brake, pull the harness adjustment strap until the headrest is at the
desired height, you will hear a faint "click" sound from the headrest as it locks into
position. Check that the headrest can not be pulled down any further and activate
the headrest brake by moving the lever (i) across to the right.
WARNING: Do not pull up the headrest with the parking brake activated.
