2.4 Installation of the hob

DANGER!
The appliance must be installed by a qualified
professional only. Do not carry out the installation
yourself. RISK OF ELECTRIC SHOCK!
(1) Before installing the hob, you may need to fix the adhesive
seal on the bottom edge of the hob properly
 The seal must be fitted tightly on the bottom edge of the
hob (no overlaps, no gaps etc.) to prevent liquids etc.
from entering the installation opening subsequently.
Mounting of the fixing brackets
(2) Install the fixing brackets on the sides of the hob using the
appropriate screws: screw one end of the fixing brackets
into the predrilled holes on the sides of the hob (s. fig.
below).
Depending on model.
6
(3) Insert the hob into the installation opening and push it
downward carefully until the hob and the seal are in firm
contact to the worktop (s. fig. below).
 The hob must be ventilated properly. The air inlet and outlet
must never be blocked or covered.
.
6
1 WORKTOP
2 SCREW
3 BRACKET
4 HOB
5 SEAL
47
