7 Air out baffle
8 Cyclone cover ring
9 Cyclone cover
10 Cyclone cylinders
11 FE net
12 Dust cup bottom seal
C. Battery assemble
1 Battery cover
2 Battery PCB
3 Battery left lining
4 Battery contact piece
13 Dust cup cover
14 Spring
15 Ventilation cover lock
16 Dust cup
17 Dust cup bottom seal
5 Pin baffle
6 Battery
7 Battery right lining
8 Battery left lining
